Boss Audio
Boss Audio BE600.4D Elite 4-Channel 600W RMS Class-D Full-Range Car Amplifier
Boss Audio BE600.4D Elite 4-Channel 600W RMS Class-D Full-Range Car Amplifier
Regular price
$259.99 USD
Regular price
Sale price
$259.99 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
BRAND NEW
BOSS ELITE BE600.4D
4-Channel 600 Watts RMS Class-D Full-Range Car Audio Amplifier
Key Features:
- Bridgeable
- PWM MOSFET Power Supply
- Thermal, Short, and Overload Protection Circuits
- Full Range 4-Channel Class D Amplifier
- High Pass and Low Pass Filters 50Hz-250Hz
- Bass Boost 0dB- +12dB
- Bridgeable
- PWM MOSFET Power Supply
- Thermal, Short, and Overload Protection Circuits
- RCA or Speaker Level Inputs
- Low Level Input Voltage 400mV-4V
- High Level Input Voltage 4V-40V
- 100W RMS X 4 CH @ 4Ω
- 150W RMS X 4 CH @ 2Ω
- 300W RMS x 2 CH @ 4Ω Bridged
Specifications:
General
Amp Topology: Full Range, Class D
Power Supply Type: MOSFET Power Supply
Performance
Total Power Output: 1200 Watts
Peak Power @ 2 Ω: 300 Watts x
Peak Power @ 4 Ω: 150 Watts x
Bridged Power @ 4 Ω: 600 Watts x
RMS Power @ 2 Ω: 225 Watts x
RMS Power @ 4 Ω: 113 Watts x
Bridged RMS Power @ 4 Ω: 450 Watts x
Speaker Impedance: 2 to 8 Ω
T.H.D. (Total Harmonic Distortion): 0.01 %
Channel Separation ≥: 90 dB
Frequency Response: 9 Hz to 50 " " kHz ±1 dB
Connections, Controls, and Processing
RCA Inputs: 4 Channel
High Level Inputs: ✔
Low Pass Filter: 50 Hz to Hz
High-Pass Filter: Variable " " Hz " " Hz
Bass Boost: Variable " " " " " " dB
Subwoofer Level Control: ✔
Input Sensitivity Switch: ✔
Thermal/Overload/Short Protection: ✔
Mounting Measurement
Length: 4.57 "
Width: 9.76 "
