DS18 6JP300N-4 6.5" 300W Max 4-Ohm Car Audio Full-Range Loudspeaker (Single)

DS18 6JP300N-4 6.5" 300W Max 4-Ohm Car Audio Full-Range Loudspeaker (Single)

$107.95 USD
$107.95 USD
Sale Sold out
Shipping calculated at checkout.
BRAND NEW

DS18 6JP300N-4

6.5-inch 300 Watts Max 4-Ohm Full-Range Loudspeaker (Single)

Key Features:

  • 6.5" Full-Range
  • MAX Power: 300 Watts
  • RMS Power: 150 Watts
  • Impedance: 4-Ohm
  • Neodymium Magnet
  • 97dB
Specifications:

  • SKU: 6JP300N-4
  • Nominal Diameter: 6.5" / 165mm
  • Nominal Impedance: 4 Ohms
  • RMS Power Handling: 150W
  • MAX Power Handling: 300W
  • Sensitivity (1w/1m): 97dB
  • Frequency Response: 80Hz-10KHz
  • Recommended Hi Pass Crossover: 120Hz
  • Pair or Single: Single
Motor Features:

  • Voice Coil Diameter: 1.5" / 38mm
  • Voice Coil Former Material: Kapton
  • Winding Material: CCAW
  • Cone Material: Paper
  • Dust Cap Material: Paper
  • Surround Material: Cloth
  • Basket Material: Steel
  • Basket Color | Finish: Satin Black
  • Magnet Material: Neodymium
  • Magnet Size: 75x45x6mm
Thiele & Small Parameters:

  • Vas: 5L / 0.176ft3
  • Xmax: 3.6mm
  • Fs: 140Hz
  • Qms: 4.244
  • Qes: 0.863
  • Qts: 0.717
  • Mms: 7.515g
  • Cms: 0.1678mm/N
  • BL: 4.981
  • Le: 0.1091mH
  • Sd: 141.03cm2
  • Re: 3.2 ohms
  • Mmd: 6.508g
Measurements:

  • Overall Diameter: 6.53" / 166mm
  • Overall Depth: 2.67" / 68mm
  • Front Mount Baffle Cutout: 5.63" / 143mm
  • Mounting Depth: 2.48" / 63mm
  • Motor Diameter: 2.95" / 75mm
