DS18

DS18 6XL600-8 6.5" 600W Max 8-Ohm Mid-Range Car Audio Loudspeaker (Single)

DS18 6XL600-8 6.5" 600W Max 8-Ohm Mid-Range Car Audio Loudspeaker (Single)

$95.95 USD
$95.95 USD
Sale Sold out
Shipping calculated at checkout.
BRAND NEW

DS18 6XL600-8

XL Series | 6.5-inch 600 Watts Max 8-Ohm Mid-Range Loudspeaker (Single)

Key Features:

  • 6.5" Mid-Range
  • MAX Power: 600 Watts
  • RMS Power: 300 Watts
  • Impedance: 8-Ohm
  • Ferrite Magnet
  • 97dB
Specifications:

  • SKU: 6XL600-8
  • Nominal Diameter: 6.5" / 165mm
  • Nominal Impedance: 8 Ohm
  • RMS Power Handling: 300 Watts
  • MAX Power Handling: 600 Watts
  • Sensitivity (1w/1m): 97dB
  • Frequency Response: 60Hz-12.5KHz
  • Recommended Hi Pass Crossover: 100Hz
  • Pair or Single: Single
Motor Features:

  • Voice Coil Diameter: 2" / 50.8 mm
  • Voice Coil Former Material: Kapton
  • Winding Material: CCAW
  • Cone Material: Non-pressed Paper
  • Dust Cap Material: Paper
  • Surround Material: Cloth
  • Basket Material: Aluminum
  • Basket Color | Finish: Satin Black
  • Magnet Material: Ferrite
  • Magnet Size: 34 Oz
  • Displacement Volume: 0.45L / 0.015ft3
Thiele & Small Parameters:

  • Vas: 5.71L / 0.201ft3
  • Xmax: 3.7 mm
  • Fs: 100Hz
  • Qms: 4.93
  • Qes: 0.5
  • Qts: 0.454
  • Mms: 11.917
  • Cms: 0.214 mm/N
  • BL: 6.906
  • Le: 0.1647mH
  • Sd: 136.85 cm²
  • Re: 3.2 ohms
  • Mmd: 10.996g
Measurements:

  • Overall Diameter: 6.7" / 170mm
  • Overall Depth: 3.5" / 89mm
  • Front Mount Baffle Cutout: 5.9" / 150mm
  • Mounting Depth: 3.14" / 80mm
  • Motor Diameter: 4.96" / 126 mm
