DS18 ION1000.4D 4-Channel 3000W Peak Full-Range Class-D Compact Car Amplifier

Name: DS18 ION1000.4D 4-Channel 3000W Peak Full-Range Class-D Compact Car Amplifier
Brand: DS18
SKU: ION 1000.4D
Price: 249.95 USD
Availability: InStock

$249.95 USD

Sale Sold out

Shipping calculated at checkout.

Product variants

Quantity

BRAND NEW

DS18 ION1000.4D

4-Channel 3000 Watts Peak Full-Range Class-D Compact Car Audio Amplifier

Key Features:

Amplifier Class: Digital
Amplifier Type: Full-Range Stereo
Number of Channels: 4
Minimum Impedance: 2 Ohm (St) / 4 Ohms (Bridge)
Led Indicator: Power / Protect / Clipping
Power Input Terminal Size: 4 AWG
Fuse Size: 80A (external)
Remote Level Control: No
Cooling Fan: No
Thermal Protection: Yes
Over-Load Protection: Yes
DC Output Protection: Yes
Short Circuit Output Protection: Yes
Voltage Input Protection: Yes
Clipping Protection: Yes
Body Color / Finish: Aluminum Black / Silver

Specifications:

SKU: ION1000.4D
Total Watts (Peak): 3000W
RMS Power @ 4 ohm: 4 x 150W
RMS Power @ 2 ohm: 4 x 250W
RMS Power @ 1 ohm: N/A
RMS Power @ 4 ohm Bridge: 2 x 500W

Audio Features:

Frequency Response: 10Hz-20KHz
Signal to Noise Ratio: >95dB
Efficiency @ 4 ohm: 88%
Damping Factor: 210
Input Impedance: 27Kohms
Channel Separation: 59dB
Total Harmonic Distortion (THD): 0.01%
Low-Level Input Range: 0.2-6V
High-Level Input: Yes
Selectable X-Over: LPF/HPF/FULL
X-Over Filter Range: 40Hz-2KHz
Bass Boost Range: 0~12dB
Bass Boost Frequency: 45Hz

Extra Features:

Hi-Level Speaker connector: Yes
Tiffany RCA Terminal: Yes
LED Clip Indicator: Yes
High-Efficiency Micro Digital Design: Yes

Measurement:

Overall Length: 6.14" / 156mm
Overall Wide: 4.72" / 120mm
Overall Height: 2" / 52mm
Heatsink Length: 4.84" / 123mm
Gross Single Unit Weight: 0.8Kg
