BRAND NEW

DS18 NXL-IQ6/WH

6.5-Inch 2-Way 300W Max Marine Coaxial Speakers w/ Digital LED Lights (White)

Key Features:

  • 6.5" 2-Way Coaxial Marine Speaker
  • RMS Power: 150 Watts
  • Impedance: 4 Ohm ~ 95dB
  • Ferrite & Neodymium Magnets
  • Digital LED Lighting ~ IP65
  • White ~ Pair ~ Silicone Speaker Covers
Specifications:

  • SKU: NXL-IQ6/WH
  • Nominal Diameter: 6.5" / 165mm
  • Nominal Impedance: 4 ohms
  • RMS Power Handling: 150W
  • MAX Power Handling: 300W
  • Sensitivity (1w/1m): 95dB
  • Frequency Response: 45Hz-20KHz
  • Number of Ways: 2-Ways
  • Recommended High-Pass Crossover: 60Hz
  • Sold in Pair or Single: Pair
Body Features:

  • UV Protection: Yes, 100% Stable
  • Marine Grade Type: IP65
  • LED Lights: Yes, Digital LED integrated (behind cone)
  • Digital LED Connection Type: 12V & Digital IN/OUT terminal
  • Digital LED Chip Type: 1815S
  • Grill Type: Injection Molded Composite ASA with UV Protection coating
  • Color / Finish: White
Woofer Specs:

  • Voice Coil Diameter: 1.5" / 38.6mm
  • Voice Coil Former Material: Glass Fiber
  • Winding Material: CCAW
  • Cone Material: PPI
  • Dust Cap Material: PPI
  • Surround Material: Rubber
  • Basket Material: Injection Molded Composite PC with UV Protection coating
  • Magnet Material: Ferrite+Neodymium
  • Magnet Weight: 13 oz + 1.1 oz
Tweeter Specs:

  • Type: Floating Bullet Tweeter
  • Voice Coil Diameter: 1" / 25.4mm
  • Voice Coil Former Material: Kapton
  • Winding Material: CCAW
  • Diaphragm Material: Aluminium
  • Bullet Material: Injection Molded Composite PC with UV Protection coating
  • Magnet Material: Neodymium (N35H)
  • Magnet Weight: 0.4 oz
Thiele Small Parameters:

  • Equivalent Volume Vas: 3.15L / 0.11ft3
  • Excursion (one way) Xmax: 3mm
  • Free Air Resonance Fs: 94Hz
  • Mechanical Factor Qms: 7.497
  • Electrical Factor Qes: 1.205
  • Total Factor Qts: 1.038
  • Moving Mass Mms: 16.603 g
  • Compliance Cms: 0.1679 mm/N
  • Bl Factor BI: 5.138
  • Voice Coil Inductance Le: 1.4 mH
  • Diaphragm Area Sd: 114.99cm2
  • DC Resistance Re: 3.3 Ohms
  • Efficiency Bandwidth Product EBP: 78.8
Measurements:

  • Overall Diameter: 7" / 177mm
  • Overall Depth: 3.75" / 95mm
  • Front Mount Baffle Cutout: 5.3" / 135mm
  • Mounting Depth: 2.5" / 63mm
  • Motor Diameter: 3.75" / 95mm
