DS18 NXL-M2 1500W Peak 2-Channel Full-Range Class-D IPX5 Marine Grade Amplifier

DS18 NXL-M2 1500W Peak 2-Channel Full-Range Class-D IPX5 Marine Grade Amplifier

Regular price $349.95 USD
Regular price Sale price $349.95 USD
Sale Sold out
Shipping calculated at checkout.
BRAND NEW

DS18 NXL-M2

1500 Watts Peak 2-Channel Full-Range Class-D IPX5 Marine Grade Amplifier

Key Features:

  • Hardware resistant to corrosion and UV Protection
  • Coated 4 Layers PCB to prevent corrosion
  • High-level input for radio use
  • 2 Tinned OFC RCA Inputs and Outputs
  • IPX5 Water Resistance Grade
  • Front cover to keep the controls safe to the elements
  • LED Clip Indicator to easier adjustment
  • Stable and Reliable Class D Circuit Design
  • Sound Quality Verification Using AP Instruments
  • Direct Insert Power and Speaker Terminals
  • Short Circuit, Thermal, and Voltage Protection
Specifications:

POWER
  • Total Watts (Peak) 1500W
  • RMS Power @ 4 ohm 2 x 250W
  • RMS Power @ 2 ohm 2 x 400W
  • RMS Power @ 4 ohm Bridge 1 x 880W
AUDIO
  • Frequency Response: 20Hz - 20KHz
  • Signal to Noise Ratio: >90dB
  • Efficiency @ 4ohm: >90%
  • Channel Separation: >55dB
  • Total Harmonic Distortion (THD): <0.15%
  • Low-Level Input Range: 0.2V-6V
  • High-Level Input Yes: ≥5V
  • Selectable X-Over: HPF/LPF/FULL
  • X-Over Filter Range: 40Hz - 2KHz
  • Bass Boost Range: 0-12dB
  • Bass Boost Frequency: 45Hz ±5Hz
  • Phase Selector: No
FEATURES
  • Amplifier Class: Digital (D)
  • Amplifier Type Stereo: Full Range
  • Number of Channels: 2 Channels
  • Minimum Impedance: 2 ohm (Stereo) / 4 ohm (Bridge)
  • Led Indicator: Clipping / Protect / Power
  • Power Input Terminal: Size 4 Ga
  • Fuse Size: 80A (2x40A)
  • Thermal Protection: Yes
  • Over-Load Protection: Yes
  • DC Output Protection: Yes
  • Short Circuit Output Protection: Yes
  • Voltage Input Protection: Yes
  • Clipping Protection: Yes
  • Body Color / Finish Gray+White / Aluminum+ABS
EXTRA FEATURES
  • Water Resistant Rated: Yes, IPX5 (Water Splashing)
  • PCB Layout Design: 4 Layers / Coated
  • RCA Output: Yes, 2 CH (Left / Right)
  • UV Compliant: Yes, UV Protected, and PCB Coated
  • Input Sum Selector: N/A
  • Tiffany Style RCA: Yes
  • High-Level Input: Yes, 2ch Speaker level
  • Stainless Steel Hardware: Yes, (Screws)
  • Potentiometers High-Quality Metal Knob
  • Remote Level Control: No
MEASUREMENT
  • Overall Length 9.6" / 245mm
  • Overall Wide 4.5" / 116mm
  • Overall Height 1.7" / 43mm
  • Heatsink Length  8.6" / 220mm
GREAT FOR
  • Marine Audio
  • Jeep Audio
  • ATV Audio
  • Powersports Audio
