DS18 NXL-X1200.5D 5-Channel 2800W Max Class-D Full-Range Marine Audio Amplifier
DS18 NXL-X1200.5D 5-Channel 2800W Max Class-D Full-Range Marine Audio Amplifier
Regular price
$699.99 USD
Regular price
Sale price
$699.99 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
BRAND NEW
DS18 NXL-X1200.5D
NXL SERIES | 5 Channel 2800 Watts Max Class-D Full-Range Stereo Marine Amplifier
FEATURES
- Amplifier Class: Digital
- Amplifier Type: Stereo Full Range + Subwoofer
- Number of Channels: 5
- Minimum Impedance: 2 Ohms (Stereo) / 4 Ohm (Bridge) / 2 Ohm (SUB)
- Led Indicators: Power / Protection / Clip
- Power Input Size: 4GA Tinned OFC
- Fuse Size: 2 x 50A (100A)
- Thermal Protection: Yes (75°C)
- Over-Load Protection: Yes
- Short Circuit Output Protection: Yes
- Voltage Input Protection: Yes (7-16V)
- Body Color / Finish: Black Brushed Aluminum
POWER
- Total Watts (Peak): 2800W
- RMS Power @ 4 ohm : 4 x 150W + 350W (SUB)
- RMS Power @ 2 ohm : 4 x 200W + 600W (SUB)
- RMS Power @ 1 ohm : -
- RMS Power @ 4 ohm Bridge: 2 x 400W
AUDIO
- Frequency Response: 10Hz-20KHz
- Signal to Noise Ratio 1W@4Ω: > 100dB
- Efficiency @ 4ohm: 0.85
- Input Impedance: 20KΩ
- Channel Separation: 60dB
- Total Harmonic Distortion (THD): < 0.05%
- Low Level Input Range: 200mV-5V
- Selectable X-Over: Yes (HPF/Full/LPF) / LPF Fixed (SUB)
- X-Over Filter Range: 40Hz-2KHz / 50Hz-250Hz (SUB)
- Bass Boost Range: 0-18dB (SUB)
- Bass Boost Frequency: 42Hz (SUB)
- Infrasonic Filter: 10Hz-55Hz (SUB)
- Phase Selector: No
MEASUREMENT
- Overall Length: 12.67" / 322mm
- Overall Wide: 4.4" / 112mm
- Overall Height: 1.77" / 45mm
- Heatsink Length: 11.87" / 301.7mm
- Gross Single Unit Weight: 2.4kg
