DS18 NXL-X1500.1FR 1CH Monoblock Full-Range Class-D Marine Powersports Amplifier
DS18 NXL-X1500.1FR 1CH Monoblock Full-Range Class-D Marine Powersports Amplifier
Regular price
$549.95 USD
Regular price
Sale price
$549.95 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
BRAND NEW
DS18 NXL-X1500.1FR
1-Channel Monoblock 3000 Watts Peak Full-Range Class-D Marine Powersports Amplifier
Elevate your marine sound experience to new heights with DS18's NXL-X1500.1FR. Designed to deliver the best performance for your marine speakers, this digital class amplifier is the ultimate choice for those who refuse to settle for anything less than exceptional.
Key Features:
- Amplifier Class: Digital
- Amplifier Type: Full Range
- Number of Channels: 1
- Minimum Impedance: 1 Ohm
- Led Indicator: Power | Protection | Clip
- Power Input Size: 4GA Tinned OFC
- Fuse Size: 150A
- Thermal Protection: Yes (75C)
- Over-Load Protection: Yes
- Short Circuit Output Protection: Yes
- Voltage Input Protection: Yes (7-16V)
- Body Color | Finish: Black Brushed Aluminum
Specifications:
- SKU: NXL-X1500.1FR
- Total Watts (Peak): 3000W
- RMS Power @ 4 ohm: 700W
- RMS Power @ 2 ohm: 1000W
- RMS Power @ 1 ohm: 1500W
Audio Specs:
- Frequency Response: 10Hz-250Hz
- Signal to Noise Ratio 1W @ 4?: >81dB
- Efficiency @ 4 ohm: 92%
- Input Impedance: 20K OHM
- Total Harmonic Distortion (THD): <0.05%
- Low-Level Input Range: 200mV-5V
- Selectable X-Over: Band-Pass
- X-Over Filter Range: LPF: 50Hz-20KHz / HPF: 10Hz-500Hz
- Bass Boost Range: 0-18dB
- Bass Boost Frequency: 42Hz
- Phase Selector: 0-180
Extra Features:
- Waterproof Rating: IP67
- UV / Salt Fog Protection: Yes
- Direct Power Harness Design: Yes
- Quick Connect Plug: Yes
- Surface Mount Component Technology: Yes
- Marine Grade Fuse Holder: Yes
Measurements:
- Overall Length: 13.4" / 341mm
- Overall Wide: 4.4" / 112mm
- Overall Height: 1.77" / 45mm
- Heatsink Length: 11.8" / 301mm
- Gross Single Unit Weight: 2.7kg
