DS18

DS18 PRO-NEO10R 10" 1000W Max 4-Ohm Mid-Range Car Audio Neodymium Loudspeaker

Name: DS18 PRO-NEO10R 10" 1000W Max 4-Ohm Mid-Range Car Audio Neodymium Loudspeaker
Brand: DS18
SKU: PRO-NEO10R
Price: 287.95 USD
Availability: InStock

$287.95 USD

Sale Sold out

Shipping calculated at checkout.

Product variants

Quantity

BRAND NEW

DS18 PRO-NEO10R

10-inch 1000 Watts Max 4-Ohm Mid-Range Neodymium Loudspeaker

Key Features:

10" Mid-Range
MAX Power: 1000 Watts
RMS Power: 500 Watts
Impedance: 4-Ohm
Neodymium Magnet
Aluminum Basket

Technical Data:

SKU: PRO-NEO10R
Nominal Diameter: 10"
Nominal Impedance: 4 ohms
RMS Power Handling: 500W
Maximum Power Handling: 1000W
Sensitivity (1w/1m): 98 dB
Frequency Response: 60Hz - 11KHz
Recommended Hi Pass Crossover: 120 Hz
Voice Coil Diameter: 2.5" /65.5 mm
Voice Coil Former Material: Ti
Winding Material: CCAW
Basket Material: Aluminum
Magnet Weight:
Sold In: Piece

Thiele & Small Parameters:

Vas: 12.5 L
Xmax: 12 mm
Fs: 102 Hz
Qms: 1.158
Qes: 0.316
Qts: 0.248
Re: 3.2 ohms

Measurements:

Overall Diameter: 10.3" / 261mm
Front Mount Baffle Cutout: 9" / 229mm
Mounting Depth: 4.3" / 109
Overall Depth: 4.8" / 121.4mm
Product Weight: 8.5 lbs
Product Dimensions: 10.875 x 10.875 x 5.25
