DS18 SDX-P100 1-DIN AM/FM/USB/APP/DSP/Bluetooth Mechless Digital Media Receiver

DS18 SDX-P100 1-DIN AM/FM/USB/APP/DSP/Bluetooth Mechless Digital Media Receiver

$179.95 USD
$179.95 USD
Sale Sold out
Shipping calculated at checkout.
BRAND NEW

DS18 SDX-P100

Single-DIN AM/FM/USB/APP/DSP/Bluetooth Mechless Digital Media Receiver

Key Features:

  • Digital Media Single Din Receiver
  • Mech-Less ~ Remote Control APP
  • BT ~ USB ~ AUX
  • DSP ~ EQ ~ AM/FM
  • SUB Output ~ SWC Output
  • Multi-Color Illumination~ 4" Display
General Specifications:

  • SKU: SDX-P100
  • Nominal DIN Size: 1-DIN
  • Rated Power Voltage: 14.4V
  • Voltage Operation: 9.6-15 Volts
  • Maximum Current Consumption: 15A
  • Temperature Operation: 0~60°C / 32~140°F
  • Screen Size: 4" / 104mm
  • Display Type: LCD Dots
  • Buttons / Controls: ABS
  • Backlight Illumination Type: RGB / 3 Zones
  • Body Material / Color / Finish: Steel / Bronze
Audio Specs:

  • Maximum Power Output (Peak): 4x40W
  • Continuous Power Output (RMS): 4x15W
  • Minimum Impedance: 4 Ohms
  • Frequency Response: 20Hz-20KHz
  • Pre-Output Level (RCA): 3V / 3.5V (Subwoofer)
  • Equalizer Bands: 24 Bands
  • Equalizer Gain: + / - 9dB
  • Crossover: 3-Way
  • Crossover Slope: 6 / 12 / 24 dB/Oct
  • Time Alignment: 0~25ms / 0~850cm
  • Audio Control: Subwoofer Level, Fader, Balance, Loudness
Tuner & BT Specifications:

  • Frequency Range (FM): 87.5 - 108.0 MHz
  • Frequency Range (AM): 522 - 1620 KHz
  • Presets Memory: 18 FM / 12 AM
  • Region: Europe, America, Asia, Russia
  • Sensitivity Adjustment: Local / DX
  • Version: 4.2
  • Services: Hands Free Calls, Audio Streaming, APP Remote Control
  • Audio Protocols: A2DP, AVRCP, HFP
  • Range: 32ft / 10m
USB / SD Player Specifications:

  • Type / Class: 2.0, 3.0 / FAT 16, FAT32
  • Format Files Supported: FLAC (16 Bit), WAV, AAC, APE, MP3
  • Max Memory Size Reader: 64 Gb
  • Max Current USB Charger: 1A
  • Number of Ports: 1 (Front)
Connectivity Specifications:

  • A/V Aux Input: Yes, Front 3.5mm Jack (2V Max)
  • Microphone: Yes, Built-In / External Mic Input
  • Remote Control (SWC): Yes, 3.5mm Jack Input
  • Remote Control (Handset): Yes, Card Type with Rubber Buttons
  • APP Control: Yes, (Android Devices)
Measurements:

  • Overall Width (Chassis): 7" / 178mm
  • Overall Height (Chassis): 1.96" / 50mm
  • Overall Depth (Chassis): 4" / 104mm
  • Overall Width (Bezel Frame): 7.4" / 188mm
  • Overall Height (Bezel Frame): 2.2" / 58mm
  • Overall Depth (Bezel Frame): 0.98" / 25mm
