DS18 SXE-1200.4/RD 1200W Peak 4-Channel Class-A/B Full-Range Car Audio Amplifier
DS18 SXE-1200.4/RD 1200W Peak 4-Channel Class-A/B Full-Range Car Audio Amplifier
Regular price
$129.95 USD
Regular price
Sale price
$129.95 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
BRAND NEW
DS18 SXE-1200.4 (RED)
SXE Series | 1200 Watts Peak 4-Channel Class-A/B Full-Range Car Amplifier
Key Features:
- Compact size for easy installation anywhere
- Stable Two or Four Layer-Traced PCB Design
- Audio Precision Quality Control Verification
- Full Adjustable HP/LP @ 12dB/oct Crossover
- Various Forms of Electronic Protection
Specifications:
- Total Watts (Peak): 1200W
- RMS Power @ 4 ohms: 4 x 60W
- RMS Power @ 2 ohms: 4 x 100W
- RMS Power @ 1 ohm: /
- RMS Power @ 4 ohms Bridge: 2 x 200W
- Frequency Response: 10Hz-20KHz
- Signal to Noise Ratio: 90dB
- Efficiency @ 4 ohms: 64%
- Damping Factor: 170
- Input Impedance: 20kΩ
- Channel Separation: 45dB
- Total Harmonic Distortion (THD): 0.05%
- Low-Level Input Range: 200mV-5V
- High-Level Input: /
- Selectable X-Over: HPF/FULL/LPF
- X-Over Filter Range: 40Hz-2KHz
- Bass Boost Range: /
- Bass Boost Frequency: /
- Infrasonic Filter: /
- Phase Selector: /
- Amplifier Class: Analog (AB)
- Amplifier Type: Stereo Full Range
- Number of Channels: 4
- Minimum Impedance: 2 Ohms Stereo / 4 Ohms Bridge
- Led Indicator: Power/Protect/Clip
- Power Input Terminal Size: 4Ga
- Fuse Size: 2 x 25A (50A)
- Remote Level Control: /
- Cooling Fan: Yes
- Voltmeter: /
- Thermal Protection: Yes (80℃)
- Over-Load Protection: Yes
- DC Output Protection: Yes
- Short Circuit Output Protection: Yes
- Voltage Input Protection: Yes (16.5v)
- Clipping Protection: Yes
- Body Color / Finish: Red Brushed Aluminum
- Overall Length: 9.8" / 249.3mm
- Overall Wide: 5.5" / 140mm
- Overall Height: 1.8" / 48mm
- Heatsink Length: 8.34" / 212mm
- Gross Single Unit Weight: 1.76KG
