BRAND NEW

DS18 ZXI.6

6-Channel 5400 Watts Peak 2-4 Ohm Stable Full Range Class-D Amplifier

The ZXI.6 is one of the most versatile amplifiers in our catalog: this Full-Range 6-Channel Amplifier outputs enough power to supercharge any powerful competitive or casual sound system!

Key Features:

  • Amplifier Class: Digital
  • Amplifier Type: Stereo Full Range
  • Number of Channels: 6
  • Minimum Impedance: 2 ohm (Stereo) / 4 ohm (Bridge)
  • Led Indicator: Power/Protection/Clip
  • Power Input Terminal Size: 4GA
  • Fuse Size: 160A (External)
  • Thermal Protection: Yes (>160°F / 71°C)
  • Over-Load Protection: Yes
  • DC Output Protection: Yes
  • Short Circuit Output Protection: Yes
General Specs:

  • SKU: ZXI.6
  • Total Watts (Peak): 5400W
  • RMS Power @ 4 ohm: 6 x 200W
  • RMS Power @ 2 ohm: 6 x 320W
  • RMS Power @ 4 ohm Bridge: 3 x 640W
Audio Features:

  • Frequency Response: 20Hz-20KHz
  • Signal to Noise Ratio: >90dB
  • Efficiency @ 4ohm: >85%
  • Damping Factor: >200
  • Total Harmonic Distortion (THD): <0.3%
  • Low-Level Input Range: 0.2 - 6v
  • High-Level Input: No
  • Selectable X-Over: LPF/FULL/HPF
  • X-Over Filter Range: 50Hz-5KHz
  • Bass Boost Range: No
  • Bass Boost Frequency: No
  • Infrasonic Filter: No
  • Phase Selector: No
Extra Features:

  • Voltage Input Protection: Yes
  • Clipping Protection: Yes
  • Body Color / Finish: Black Aluminum Brush
  • Tiffany RCA connectors: Yes
  • Input Selector: Yes (4ch/6ch)
  • Compact Size to easy Installation for Any Applications: Yes
  • Stable/Reliable Two Layers Traces PCB Design: Yes
  • Quality Control Verification using Audio Precision Instruments: Yes
Measurement:

  • Overall Length: 12.2" / 310mm
  • Overall Wide: 5.66" / 144mm
  • Overall Height: 1.9" / 48.5mm
  • Heatsink Length: 11.42" / 290mm
  • Gross Single Unit Weight: 6 lb / 2.72 kg
