JVC

JVC KW-M690BW 6.8" Digital Multimedia Receiver w/ Apple CarPlay & Android Auto

$399.00 USD

Sale Sold out

Shipping calculated at checkout.

Product variants

Quantity

BRAND NEW

JVC KW-M690BW

Digital Media Receiver featuring 6.8" Capacitive Touch Monitor / Apple CarPlay® (Wireless, Wired) / Android Auto™ (Wireless, Wired) / Wireless Mirroring / Bluetooth® / 13-Band EQ / Short Chassis

Monitor Specs:

Screen Size: 6.8"W SVGA

Touch Panel: Capacitive

Key Illumination Color: Blue

Dimmer: Yes

Multilingual Display: Yes[4]

Media Playback:

MP3 Compatible with Tag: USB

WMA Compatible with Tag: USB

WAV Compatible with Tag: USB

AAC Compatible with Tag: USB

FLAC Compatible with Tag: USB

H.264 Compatible: USB

WMV Compatible: USB

MPEG 1/2 Compatible: USB

MPEG 4 Compatible: USB

MKV Compatible: USB

Bluetooth Control:

Built-in Bluetooth[1]: Yes (Hands-Free MIC Built-in)

Hands Free Call: Yes (HFP1.7)

Audio Streaming & Control (A2DP, AVRCP): Yes

Supported Audio Formats: AAC / SBC

Voice Dialing (voice recognition compatible mobile phone required): Yes

Phone Book Access Profile (PBAP): Yes

Wi-Fi Control:

Built-in Wi-Fi: Yes

Android Control:

Android Auto[2]: Yes (via Wi-Fi or USB)

Mirroring for Android: Yes (via Wi-Fi) *Need mirroring App

iPod/iPhone Control:

CarPlay[3]: Yes (via Wi-Fi or USB)

Mirroring for iPhone: Yes (via WiFi) *Need mirroring App

USB:

USB Port: x 1 (High Speed)

Position: Rear

USB Power Supply: Yes (2.1A High Current Charging)

Radio Tuner:

Radio Broadcast Data System (RBDS): Yes

Preset Stations: 36(FM:24ch, AM:12ch)

Auto Memory Entry: Yes

FM Frequency Range: 87.9 - 107.9MHz

AM Frequency Range: 530-1,700kHz

Audio:

Maximum Power Output (Front & Rear): 50Wx4

Full Bandwidth Power (Front & Rear): 22W x 4

EQ: Yes (13-Band Graphic EQ)

Preset EQ: Yes (7Preset + 3user)

Bass Boost: Yes

High-Pass Filter/Low-Pass Filter: Yes/Yes

Speaker Size Control: Yes

Inputs and Outputs:

Video Out: x 1 (V:RCA)

Rear view camera Input: Yes

Line Output Terminals: 2Preouts + Sub WF (Mono)

Pre-output Level/Impedance: 2.5V / 10k ohms

Subwoofer Output with Level/Frequency Control: Yes (Normal / Reverse)

General:

Short Chassis: Yes

Wireless Remote Control: Optional (RM-RK259 required)

Steering Remote Control Ready: Yes

Dimensions (W x H x D) / Weight

Installation Size: 7" x 3-15/16" x 3-3/8" (178 x 100 x 85.7 mm)

Weight: 2.3 lbs. (1.03kg) Including Trim plate

Unit weight in individual package: 1.53kg

View full details
