Orion

Orion XTRPRO4.1K 4-Channel 310W RMS x 4 @ 1-Ohm Class-D Full-Range Car Amplifier

Orion XTRPRO4.1K 4-Channel 310W RMS x 4 @ 1-Ohm Class-D Full-Range Car Amplifier

Regular price $299.95 USD
Regular price Sale price $299.95 USD
Sale Sold out
Shipping calculated at checkout.
PayPal payment Venmo payment Affirm payment
BRAND NEW

ORION XTRPRO4.1K

XTRPRO Series | 4-Channel 310W RMS x 4 @ 1-Ohm Class-D Full-Range Car Amplifier

KEY FEATURES:

High-Efficiency, Compact Power Delivery: The XTRPRO4.1K delivers up to 310 watts per channel at 1 ohm, offering more than enough output to push mids, highs, and even midbass drivers with clean, distortion-free power. It’s ideal for compact builds that still demand serious performance without overloading electrical systems or consuming excessive space.

Full-Range Versatility Powered by IntelliTech: With Orion’s IntelliTech full-range architecture, this amp is capable of powering everything from tweeters to subwoofers—all while maintaining exceptional signal clarity and thermal stability. Its design makes it the go-to solution for installers and audio builders who need flexible amplification in a single chassis.

Detailed Tuning Control for Precision Sound: Equipped with fully adjustable high-pass and low-pass filters, plus a 12dB variable bass boost, the XTRPRO4.1K gives you total control over your frequency response. Fine-tune your system’s balance, eliminate overlap, and ensure every driver is dialed in for its optimal performance range.

Reliable Operation Under Pressure: Built with robust internal protection circuits, this amplifier monitors temperature, load, and voltage conditions in real time to prevent shutdowns or failures during demanding playback. It’s made to handle long sessions, high volumes, and extreme conditions—day in and day out.

Ultra-Compact for Clean Installs: Measuring just over 11 inches in length, the XTRPRO4.1K is small enough to fit in glove compartments, seat cavities, trunk sides, and more. Its size makes it the perfect choice for stealth installations, motorcycles, side-by-sides, or any application where space is at a premium but sound quality can’t be compromised.


SPECIFICATIONS:

Power Rating
- RMS Power @ 4 Ohms: 150W x 4CH
- RMS Power @ 2 Ohms: 220W x 4CH
- RMS Power @ 1 Ohm: 310W x 4CH
IntelliTech Full-Range Class D Design
1-Ohm Stable on All Channels
High-Pass Filter: 40Hz – 500Hz
Low-Pass Filter: 40Hz – 300Hz
Bass Boost: 0 – 12dB
Gain Control: 200mV – 6V
Signal-to-Noise Ratio: >94dB
Damping Factor: >100
Remote Gain Controller Included
Thermal and Short Circuit Protection
Heavy-Duty Power & Speaker Terminals
11.02” x 5.90” x 2.16” (280mm x 150mm x 55mm)

Power Terminal Management:

Positive Terminals: 1 x 4 AWG.
Negative Terminals: 1 x 4 AWG.
Remote Turn-ON Signal: 10 AWG.
Speaker Output Terminals: 4 AWG.
